Automatic Checkweigher in the UAE | Reliable
An automatic checkweigher checks product weight as packs move along a production line. Reliable Industrial Group offers checkweighing solutions in the UAE for packaged goods. First, share your product size, target weight and line speed. Then, we can review the right conveyor layout and rejection method for your application.
Why Use an Automatic Checkweigher?
Weight checks help production teams spot packs outside the selected limits. For example, an underweight pack may indicate a filling issue. An overweight pack, meanwhile, may mean unnecessary product giveaway. Therefore, checking weight during production provides useful feedback before goods leave the line.
However, weight alone does not confirm every aspect of product quality. It should form part of a wider inspection process. For instance, damaged packaging and incorrect labels need their own checks.
Compact Checkweighing for Packaged Products
This configuration range covers products from 15 g to 8 kg, with throughput up to 400 packs per minute. In addition, its modular structure supports integration with marking, vision and barcode systems. Touchscreen options include 7, 10 and 15 inches.
| Feature | Available specification |
|---|---|
| Product weight range | 15 g to 8 kg |
| Maximum throughput | Up to 400 packs per minute |
| Conveyors | 1 to 6, depending on configuration |
| Protection | IP54; IP65 optional |
| Product handling | Bags, trays, boxes, bottles, cans and jars, subject to application review |
Actual performance depends on product shape, size, weight and line conditions. Therefore, the maximum speed and full weight range should not be treated as simultaneous guarantees. We recommend confirming the required performance with representative samples.
Rejection Options for Your Production Line
Available rejection arrangements include air jets, pushers, diverters and drop-down systems. However, the choice depends on pack stability and handling needs. For example, a fragile pack may need a different approach from a rigid carton. Optional safety devices include reject confirmation, bin-full detection and audible-visual alarms.
How to Specify Your Automatic Checkweigher
Start with the smallest and largest products you expect to run. Next, record the conveyor height and available installation space. Also, confirm how products arrive at the weighing section and where rejected packs should go.
- Product photograph and packaging type
- Minimum, target and maximum pack weight
- Pack length, width and height
- Required packs per minute
- Weight tolerance and rejection requirements
- Conveyor height, direction and available space
- Cleaning conditions and communication needs
These details help define a useful trial. During evaluation, include normal variations in fill, pack position and spacing. As a result, the review can reflect everyday production more closely.
Frequently Asked Questions
Can it check outer boxes?
Boxes are a supported packaging format. However, the box weight, dimensions and line speed must suit the selected configuration. Send these details for review before choosing a system.
Does every application reach 400 packs per minute?
No. This is a maximum range figure. Actual throughput depends on the product and selected arrangement, so confirm it during application assessment.
Is IP65 included as standard?
No. The listed standard protection is IP54, while IP65 is optional. Therefore, describe your cleaning process when requesting a quotation.
Discuss Your Checkweigher Application
Looking for an automatic checkweigher in the UAE? Send your product details to Reliable Industrial Group. Then, request an application review and product trial to assess the proposed setup.
